WP22 (2¼Cr-1Mo, Grade 22) is the original and still widely-used chrome-moly alloy for high-temperature service. It has a massive installed base in global refineries, petrochemical plants, and power st...
WP22 (2¼Cr-1Mo, Grade 22) is the original and still widely-used chrome-moly alloy for high-temperature service. It has a massive installed base in global refineries, petrochemical plants, and power stations built from the 1960s through 2000s. Available in Class 1 (normalized) and Class 3 (quenched & tempered, higher strength). The go-to grade for replacement and maintenance of existing P22 systems.
| Property | Value |
|---|---|
| Grade | WP22 (P22) |
| ASTM / ASME | ASTM A234 WP22 Cl.1 / Cl.3 |
| UNS Number | — |
| Chromium (Cr) | 2.0–2.5% |
| Nickel (Ni) | ≤0.25% |
| Molybdenum (Mo) | 0.87–1.13% |
| Max/Min Service Temp | 600°C |
| Fitting Standard | ASME B16.9 / MSS SP-43 |
| Size Range | ½" NB to 48" NB |
| Certificate | EN 10204 3.1 MTC |
Send type, size, schedule, quantity, standard. We respond within 4 hours with pricing and availability.
